Pivot Phoenix Specs and reviews
Pivot Phoenix specs
| General Information | |
|---|---|
| Model Name | Phoenix |
| Brand/Manufacturer | Pivot |
| Year of Release | 2022 |
| Country of Origin | United States |
| Mountain Bike Type | downhill |
| Intended Use | racing |
| Frame & Geometry | |
| Frame Material | carbon |
| Frame Size Options | S, M, L, XL |
| Frame Geometry | reach: 440mm / stack: 625mm / head tube angle: 63.5 degrees / seat tube angle: 76 degrees / chainstay length: 435mm / wheelbase: 1235mm |
| Axle Standard | Boost 157mm |
| Bottom Bracket Type | PF30 |
| Headset Type | IS42/IS52 |
| Internal Cable Routing | true |
| Frame Storage | tool integration |
| Protection Features | frame armor, chainstay protector |
| Suspension System | |
| Suspension Type | full suspension |
| Front Suspension Brand and Model | Fox 40 |
| Front Suspension Travel | 200mm |
| Rear Suspension Brand and Model | Fox DHX2 |
| Rear Suspension Travel | 200mm |
| Suspension Adjustments | compression, rebound |
| Suspension Design/Kinematics | VPP |
| Flip Chip or Geometry Adjust Features | true |
| Drivetrain | |
| Drivetrain Type | 1x |
| Number of Speeds | 12-speed |
| Rear Derailleur Model | SRAM X01 |
| Shifter Brand and Model | SRAM X01 |
| Crankset Details | length: 175mm / chainring size: 32T |
| Cassette Range | 10-52T |
| Chain Type and Brand | SRAM |
| Q-Factor | n/a |
| Braking System | |
| Brake Type | hydraulic disc |
| Brake Brand and Model | SRAM Code RSC |
| Rotor Size | front: 200mm / rear: 200mm |
| Brake Mount Standard | post mount |
| Brake Pads | organic |
| Wheels & Tires | |
| Wheel Size | 27.5" |
| Rim Material and Width | aluminum, 30mm |
| Hub Type and Engagement | rapid engagement |
| Tubeless Ready | true |
| Tire Brand, Model, and Width | Maxxis Minion DHF, 2.5" |
| Tire Compound and Sidewall Casing | dual compound, EXO |
| Tire Tread Pattern and Intended Terrain | aggressive tread, loose terrain |
| Max Tire Pressure | 50 psi |
| Insert Compatibility | CushCore-ready |
| Cockpit & Contact Points | |
| Handlebar Type | riser |
| Handlebar Material | carbon |
| Stem Length and Angle | 50mm, 0 degrees |
| Grips Type | lock-on |
| Saddle Brand and Model | WTB Volt |
| Seatpost Type | dropper |
| Dropper Post Travel | 170mm |
| Seatpost Diameter | 31.6mm |
| Pedals Included | false |
| Headset Brand and Bearing Type | Pivot, sealed |
| Geometry & Fit | |
| Available Frame Sizes | S, M, L, XL |
| Standover Height | 780mm / 800mm / 820mm / 840mm |
| Rider Height Range | n/a |
| Stack and Reach | S: stack 615mm, reach 420mm / M: stack 620mm, reach 440mm / L: stack 625mm, reach 460mm / XL: stack 630mm, reach 480mm |
| Effective Top Tube Length | n/a |
| Chainstay Length | 435mm |
| Bottom Bracket Drop and Height | n/a |
| Head Tube and Seat Tube Lengths | n/a |
| Price & Availability | |
| MSRP | $6,999 |
| Market Availability | United States, Canada, Europe |
| Color Options | Black, Red |
| Warranty Coverage | frame: 5 years, components: 1 year |
Pros and Cons of Pivot Phoenix
| Pros | Cons |
|---|---|
| 1. Lightweight frame for easier handling | 1. Limited color options |
| 2. Smooth and responsive gear shifting | 2. Seat may be uncomfortable for long rides |
| 3. Excellent suspension for a comfortable ride | 3. Price is on the higher side |
| 4. Durable construction for long-lasting use | 4. May require frequent maintenance |
Common Issues and Problems with Pivot Phoenix
| Common Problems with Pivot Phoenix Bike: |
| 1. Rear suspension not functioning properly |
| 2. Dropper post sticking or not engaging |
| 3. Brakes squeaking or feeling spongy |
| 4. Gears slipping or not shifting smoothly |
| 5. Loose or creaking headset |
| 6. Wheel spokes breaking or coming loose |
User Reviews of Pivot Phoenix
| Name | Review |
|---|---|
| John | The Pivot Phoenix bike is a beast on the trails. It handles rough terrain with ease and provides a smooth ride. Highly recommended for downhill enthusiasts. |
| Sarah | I've been riding the Pivot Phoenix for a few months now and I'm extremely impressed. The bike is well-built, durable, and offers great control. Love it! |
| Mike | As an experienced rider, I can say that the Pivot Phoenix is a top-quality downhill bike. It's fast, responsive, and offers great suspension. Definitely worth the investment. |
| Emily | I recently purchased the Pivot Phoenix and I couldn't be happier. The bike is light, agile, and handles technical descents like a pro. Would recommend it to anyone looking for a high-performance ride. |
Common Questions About Pivot Phoenix
-
Is the Pivot Phoenix suitable for beginners in downhill racing?
No, the Pivot Phoenix is designed for experienced riders due to its high-performance features tailored for racing.
-
What makes the Pivot Phoenix stand out in terms of frame material?
The Pivot Phoenix's carbon frame offers a perfect balance of strength, stiffness, and lightweight construction for aggressive downhill riding.
-
Can the Pivot Phoenix accommodate different rider heights?
While it comes in various frame sizes, the Pivot Phoenix doesn't specify a specific rider height range due to the focus on frame geometries for optimal performance.
-
Are the brakes on the Pivot Phoenix easy to maintain?
Yes, the hydraulic disc brakes, specifically the SRAM Code RSC model, are known for their reliability and relatively easy maintenance.
-
Does the Pivot Phoenix come with tubeless-ready wheels?
Absolutely, the Pivot Phoenix is equipped with tubeless-ready wheels for enhanced traction, reduced punctures, and lower tire pressures.
-
What is the unique feature of the Pivot Phoenix's cockpit setup?
The Pivot Phoenix boasts a carbon riser handlebar and a dropper seatpost for better control and adaptability on challenging downhill terrains.
-
How long is the warranty coverage for the Pivot Phoenix components?
The components of the Pivot Phoenix are covered by a 1-year warranty, ensuring quality and reliability in your riding experience.
-
What sets the Pivot Phoenix's suspension system apart from others?
The Pivot Phoenix features a VPP suspension design with adjustable settings for compression and rebound, providing a customizable and responsive ride.
-
Are the tires on the Pivot Phoenix suitable for all types of terrain?
Absolutely, the Maxxis Minion DHF tires with aggressive tread patterns are ideal for loose terrains, providing excellent grip and control.
-
Can the Pivot Phoenix accommodate different tire pressures based on rider preference?
Yes, the Pivot Phoenix allows for a maximum tire pressure of 50 psi, giving riders the flexibility to adjust according to their preferences and riding style.
